Round Shallow Concrete Floor Box, Cast Aluminum, Semi Adjustable, Brass Flange

Original price was: $72.00.Current price is: $46.80.

Round Shallow Concrete Floor Box, Cast Aluminum, Semi Adjustable, Brass Flange

SKU: P740127 Category:
Description

The Lew Electric 332-DA is a round die cast aluminum concrete floor box with a brass top flange. The box is semi-adjustable offering 1″ of adjustability to be set to the level of the floor, post installation adjustability is not possible. The box is best suited for saw cut or core drilled installations, or pre-pour jobs that have 2 1/8″ to 3 5/16″ of concrete depth.  There is 13 cubic inches of interior space available, the box is only 2″ deep. There are four 3/4″ knockouts on the sides of the box to run your wires to. The box ships with a protective cement cap to keep the box clean and safe during concrete pouring. The box does not ship with a cover, there are several options available that are sold separately, Lew 4″ cover plates will fit flush. If the box is to be used in a carpeted area a sold separately carpet flange can be ordered, the SCF-1 series carpet flange adds 3/8″ of height to accommodate the carpet and padding. For tile applications no flange is needed, simply pour your concrete to the level of the tile frame less the thickness of the tile. The box is ETL listed for UL 514A in the USA, and cUL listed C22.2 #18.1 and CSA approved for Canada installations.

Top: Brass flange
Requires cover, sold separately
Size: Single gang
For concrete installations
Offers 1″ of adjustability pre-installation
13 cubic inches of interior space
Four 3/4″ knockouts
ETL and cUL listed to 514A
ETL # 4004534
CSA approved
Includes construction cap
Box dimensions:  4.25″ round
Depth:  2″ deep
Can be used with carpet or tile
Warranty:  1 year
Lew Electric 332-DA Drawing (PDF)
Lew Electric 332-DA Installation Instructions (PDF)

Specifications

Top: Brass flange
Requires cover, sold separately
Size: Single gang
For concrete installations
Offers 1″ of adjustability pre-installation
13 cubic inches of interior space
Four 3/4″ knockouts
ETL and cUL listed to # 514A
ETL # 4004534
CSA approved
Includes construction cap
Box dimensions:  4.25″ round
Depth:  2″ deep
Can be used with carpet or tile
Warranty:  1 year

Downloads

Lew Electric 332-DA Drawing (PDF)
Lew Electric 332-DA Installation Instructions (PDF)
